- Reference No.: 41705
- Manufacturer: Bobst
- Type: SP 130-ER II
- Year: 1997
- Size: 1300 x 920 mm
- Status: In Printshop
Location: Germany
Price: on request - Incoterm: FCA
- Description
- Maximum die-cutting size with front waste: 1,300 x 905 mm
- Maximum die-cutting size without front waste: 1,300 x 915 mm
- Maximum embossing size: 1,300 x 900 mm
- Paper: approximately 80–90 g/m² and above
- Solid board: up to approximately 2,000 g/m²
- Corrugated board: up to approximately 4 mm
- Equipment:
- Operating platform
- Machine raised by approximately 650 mm
- Removable platform section at the feeder
- Recently installed asynchronous main motor
- Manual non-stop feeder pallet
- Pile table with manual lateral correction during production
- Adjustable suction unit
- Automatic feeder-head adjustment
- Double-sheet detection
- Sheet down-holder for guiding sheets to the front lays
- Upper frame with manual lifting device
- Upper transport equipment for paper and cardboard
- Die-cutting, pressing/creasing and embossing, separately or simultaneously
- Oil conditioner for maintaining the correct operating temperature
- Automatic removal of internal and marginal waste
- Condition and availability
|
|
